The Gigabit Managed Cluster is a powerful, high-performance, high port-density networking system, which can upgrade and integrate your existing network from 10/100Mbps to a simplex, efficient, centralized management environment and very high-speed network architecture. As all members operate as teamwork, all connected members of the family are treated as a Single-Managed device.

The device is a 24+2-port Gigabit Clustering Switch with 24 * 10/100Mbps RJ-45 ports and 2 Gigabit slide-in slots on the rear panel for optional fiber / copper Gigabit modules.

Out of the ordinary dumb switches, the 24F.E.+2G.E. Gigabit Clustering Switch embedded advanced management capability; that the device can be remote managed by Telnet, SNMP manager and Internet browser. This is much useful for system manager to monitor and control the system efficiently.

The switch is plug-n-play without any software to configure and also fully compliant with all kinds of network protocols. Moreover, the rich diagnostic LEDs on the front-panel provide the operating status of individual port and whole system

24-P Intelligent Switch


  • The whole management stack can stack up to 8 sets

  • Proprietary management bus extend up to 800 meters for management stacking

  • Every switching port is automatically cross-over detection (MDI/ MDI-X auto-detected)

  • The 24 * RJ-45 ports support bandwidth control

  • Supports 8MB SDRAM for run time data storage

  • Supports 2MB Flash EPROM for cooperation and configuration data storage

  • Supports 3Mbit packet buffer
