| Features | |
|---|---|
|
• Support IEEE802.3, IEEE802.3u and IEEE802.ab • Support Bandwidth Control • Store-and-Forward • Flow Control: Full-duplex: IEEE802.3x, Half-duplex: Backpressure • 24 10Base-T/100Base-TXS RJ45 ports supporting MDI/MDIX • Provide DB-9 RS232 Console port supporting Out-of-Band Management • Support N-Way Auto-Negotiation • Support 6K MAC • Support Port VLAN and IEEE802.1Q Tag VLAN • Support Trunk • Support IEEE802.1x, integrated Radius • Support IGMP Snooping • Support IEEE802.1D Spanning Tree • Support MAC learning, Static MAC address Management • Support Port Sniffer • Support IEEE802.1P Priority • Support Broad-Storm Control • Support SNMP MIB-II, Ethernet-Link MIB, Bridge MIB,TP-LINK Enterprise MIB • Support RMON Statistics, History, Alarm and Event Management • Internal power in the range of 110 to 260 VAC • Operating temperature: 0°C - 40°C • Store temperature: -40°C - 70°C • Humidity: 5% -95% non-condensing | |
